New Trigger Mechanism

[ihab]

Just received the first batch of the Nile-Tec trigger mechanism.
I meant to develop a very durable trigger, something that will hold 4 x 16 mm bands comfortably and here are the results.

There are 2 models available to accommodate US shafts or Euro style shafts, form 6.5 mm shaft to 8 mm shafts.
Comes with a side release and all the pins & screws required.

Let me know what you think.

Cheers,
Ihab



[foxfish]

I think I want one, tell me how to order?



[ihab]

I think I want one, tell me how to order?

Foxfish,
You can order by following this link & I'm including 10% off for the first 10 triggers sold on DeeperBlue.....Yours being the first.
Any more details, please pm.

Cheers,
Ihab



[foxfish]

Hmmm it says the only method of payment is cash on delivery - I dont know if this is possible?



[ihab]

Hmmm it says the only method of payment is cash on delivery - I dont know if this is possible?

Foxfish,
For international orders, you just fill in your order and I will get back to you with shipping rates and a link where you could pay by Credit Card or Paypal........sorry for the confusion.

Cheers,
Ihab



[jtkwest]

looks nice. how much? does the line release reset automatically? how wide is it? will it fit into an imperial 1/2" slot? hows the pull under max pressure? still smooth? shipping will probably make it too expensive for me.



[ihab]

looks nice. how much? does the line release reset automatically? how wide is it? will it fit into an imperial 1/2" slot? hows the pull under max pressure? still smooth? shipping will probably make it too expensive for me.

jtkwest, if you could let me know where you're located, I will give you shipping cost....we have a deal running with a courier company with good prices....so give it a shot.

Must have mentioned this before but didn't:duh

There are 2 models available to accommodate US shafts or Euro style shafts, from 6.5 mm shaft to 8 mm shafts.

Outer Casing Dimensions:
- Length: 71.50 mm (2.81")
- Width : 12.75 mm (1/2")
- Height: 29.70 mm (1.17")

Made from 100% stainless steel, 1.5 mm (0.06") thick plates

Approx. weight of trigger mechanism: 110 gm (3.88 oz)


After installing/sliding the casing in the stock/wood, there will be 4 mm of the casing exposed over the wood level…….still makes the gun look unique around the trigger area.

Comes with a Life Time Guarantee……Cost $55 + shipping from Egypt.

Cheers,
Ihab
​



[jtkwest]

i live in key west florida. in the united states. also i would love to see the wood handles. i am using a metal frame which i attach two wood pieces to. i am currentlyworking on guns # 7,8,and 9. they are starting to improve andi would love to incorporate your trigger mech in one or more of them. also, the line release: does it have a spring to reset it? on the triggers i have been using, they dont reset. in fact, only the riffe triggers have this option , from what i have seen. i have been working on retro fitting a riffe spring onto another brand mechanism. here are some pics of my handles and triggers.



[slingshaft]

Lookin' good Bro! Just a couple of questions, is it really only 1/2" wide? And, is the side line release ambidextrous? I am incorrigibly right handed. Is the trigger action smooth no matter what the load? Cheers.



[foxfish]

I am looking forward to getting my unit, I have had plans in my head for a multi band gun for some time & I think this trigger is going to be part of the plan.....



[LunkerBuster]

looks great buddy, glad to see the idea come to life



[Adammoore]

Dear ihab can you explain how the side line release works ??
Thanks
